Description
NHL-3FV2 / NHP-3FV2 Network and Cloud Application Monitoring Signal Tower with LED + MP3 Audio Alert Functionality.
Monitor your network and be notified in real-time of predesignated events and device failures via visual and voice annunciator signals, and email alerts.
DOWNLOAD PDF
Product Features
【Give Your Equipment a Voice & Alleviate Staff Fatigue】
- IMPROVE OH&S AND STAFF CONDITIONS - ALLEVIATE STAFF FATIGUE by utilizing the built-in MP3 voice annunciator feature. This feature allows you to load custom voice recordings to allow the NHL to tell your operators exactly what is happening on your network.
【Quicker Response】
- Ping up to 24 devices and notify operators of ping failures in real-time with unambiguous visual and audible alerts.
【Know You're Connected】
- The green LED unit can be configured to indicate the connection status between the NHL and your network.
【Customizable to Fit Your Application】
- Standard configuration consists of a light tower with three LED segments and a programmable audible alarm with volume settings. Add up to 5 LED units for highly effective visual signaling.
【Email Notifications】
- Alarms can trigger emails to be sent to up to 8 addresses per event so you will never miss a network signal.
【Protocol Support】
- The NHL supports SNMP, HTTP, PNS (Developed by PATLITE), Socket Transmission command protocols. Alarms can send SNMP traps to network management systems.
Model Specifications
| DIMENSIONS | Tower diameter : 60mm (NHL), 40mm (NHP) | |
| OPERATING VOLTAGES | 24V DC (AC Adaptor 100V AC ~ 240V AC) | |
| PROTOCOLS | ・Physical Layer : 10 BASE-T/100 BASE-TX ・Data Link Layer : CSMA/CD ・Network Layer : IP/ICMP/B6 ・Transport Layer : TCP/UDP ・Application Layer : HTTP/RSH/SMTP/SNMP/POP/DNS/Socket/NTP/DHCP |
|
| FUNCTIONS | ・Ping Device Monitor ・RSH Command ・SNMP v1・v2C ・Application Monitor ・SOCKET ・ E-mail Transmission ・Line Out ・Easy Access Volume Control ・Preset Sound : Buzzer ; 4 Selections Chime ; 3 Selections Message ; 3 Selections |
|
| BODY STYLE | 【Interface converter】 ・Low profile steel casing ・Bumper pads installed to protect surface finish 【Tower】 ・Pre-assembled, mounted to converter base ・LED modules are interchangeable |
|
| BODY COLOR | ・Interface Converter Base : Off-white ・Tower : Off White |
|
| STACKABLE TIERS | Up to 5 LED units | |
| MODULE COLORS | ・LED source Color : Red / Amber / Green ・Lens Color : clear Lens |
|
| AUDIBLE STYLE | ・Audio File Formal : MPEG1-Audio Layer Ⅲ (MP3) Sampling Frequency 44.1kHz ・Bite Rate : 32kbit/s, 64kbit/s (Standard Rate), 128kbit/s Constant Bit Rate (CBR) Only ・Number of Playback Messages : USB Memory Transfer Package : 30 kinds Web Setup Tool Registrations : 30 kinds Preset Registrations : 10 kinds |
|
| CONFORMITY STANDARDS | ・RoHS Directive (EN 50581) ・EMC Directive (EN 55032, EN 55024) ・FCC Part15 Subpart B Class A, ICES-003 Class A ・UL 1638, UL 464 CSA C22.2 No.205 ・KC (KN 61000-6-2, KN 61000-6-4)*1 ・PSE Compliant AC Adaptor *1：Only N type and W type CE Marking UL/cUL Listed W type is an intemational model. |
|
